| Items | General Specifications |
| Phase modulation frequency(Data rate) | 10 ~ 28 Gb/s (Optional range, <10Gb/s or ~32Gb/s) |
| Programmable data rate | 10, 15, 20, 25, 28 Gb/s (User specific data rate available) |
| PRBS Patterns | 2^n -1 (n = 7, 8, 9, 10, 11, 12, User specific patterns available ) |
| Data output amplitude (single-ended) | 400mVpp |
| Data output r ise/fall time (20% to 80%) | Typ. 25ps |
| Data output jitter | 1.0 ps rms typical |
| Divided clock output | Internal clock / 16, 5 00mVpp |
| Data output external interface | 50Ω , Differential, 2.92mm K-type connector |
| Processor | FPGA |
| Size | 94 x 60 x 20 mm^3 |
| Operating temperature | +10 to +40 °C |
| Storage temperature | - 40 to +70 °C |
| Power requirements | +5V DC, 3A (AC Adaptor or Connector provided) |
